High-Pressure Hot Water Cleaner, 80 kW
Electric high-pressure hot water cleaner: 80 kW heating, 0 to 25 MPa (250 bar) adjustable, 15 L/min, water temperature from ambient up to 190 °C. 7.5 kW motor with vector frequency drive, stainless steel boiler. For heavy oil, grease and sludge removal on equipment, vehicles and floors. Not for use in hazardous areas.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
This unit combines very high pressure and high water temperature to remove heavy oil, bitumen, grease and sludge from equipment, skids, tanks, vehicles and floors. Water is pressurised first, then heated in a seamless 304 stainless steel boiler, with an adjustable outlet temperature up to 190 °C. A heavy-duty 7.5 kW motor driven by a vector frequency converter adjusts the working pressure from 0 to 25 MPa.
This is a standard industrial unit and is not explosion-proof.
Technical data
| Model | AG-CLN-112 |
| Electric heating power | 80 kW |
| Motor | 7.5 kW, vector frequency converter drive |
| Power supply | 380 V, 3-phase |
| Working pressure | 0 to 25 MPa (0 to 250 bar), adjustable |
| Water flow | 15 L/min |
| Water temperature | Ambient to 190 °C, adjustable |
| Boiler | Seamless 304 stainless steel, cast aluminium heater |
| Pump head | Imported brand |
| Operation | Control panel |
| Ambient temperature | 0 to 55 °C |
| Machine weight | 140 kg |
| Duty | 24 h continuous |
| Protections | Water shortage, overpressure, leakage, emergency stop |
Documents
Datasheet, CE and quality documents of the manufacturer, and the final configuration are confirmed with each quotation.
Supplied from a qualified manufacturer selected by ASSINOV. Origin, manufacturer details and certificates are provided with our quotation.
AG-CLN-112
Data sheet
- Power supply
- 380 V 3-phase
- Hazardous area
- Not explosion-proof
- Heating power
- 80 kW
- Working pressure
- 0 to 250 bar
- Water flow
- 15 L/min
- Water temperature
- up to 190 °C
