SONDAR RM150 Integral Radar Level Meter, 60 GHz, 15 m
All-in-one 60 GHz radar level meter with display: non-contact measurement up to 15 m (dead zone 0.2 m), 8° beam, 2-wire 4 to 20 mA loop. PVDF antenna, IP67, -30 to 70 °C. KC, FCC and CE.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The SONDAR RM150 is a non-contact radar level meter with the sensor and the controller integrated in one compact housing with a display and 5 operating buttons. Its 60 GHz frequency and narrow 8° beam give a stable measurement up to 15 m, unaffected by temperature, vapour or wind, which suits water tanks, wells, sumps, reservoirs and open channels.
It is a 2-wire loop-powered instrument (4 to 20 mA) that connects directly to a PLC, RTU or loop indicator, with a user-centred menu that shortens installation and maintenance time. A transparent cover is available for indoor installations.
Key features
- 60 GHz radar, non-contact, 15 m range
- Integral type with display and 5 buttons
- 2-wire loop power, 4 to 20 mA output
- PVDF antenna, IP67 housing
Technical data
| Model | RM150 |
| Type | Integral radar level meter with display |
| Frequency | 60 GHz |
| Measuring range | 15 m |
| Non-detectable range | 0.2 m |
| Beam angle | 8° |
| Output | 4 to 20 mA, 2-wire loop (max 30 V DC) |
| Sensor material | PVDF |
| Operating temperature | -30 to 70 °C |
| Protection | IP67 |
| Cable entry | 1/2" PF (cable gland PG 13.5) |
| Dimensions | 117 x 216.3 mm (housing width x height) |
| Certification | KC, FCC, CE |
Documents
Manufacturer catalogue attached below. Certification: KC, FCC, CE. Not certified for hazardous areas (no ATEX or IECEx certificate). Made in South Korea by SONDAR.
SONDAR-RM150
Data sheet
- Hazardous area
- Not certified
- Measuring range
- 15 m
- Output
- 4 to 20 mA, 2-wire
- Protection
- IP67
- Certification
- KC, FCC, CE
- Country of origin
- South Korea
- Technology
- Radar 60 GHz
