Flush Diaphragm Rod-Type Pressure Transmitter (hygienic, 316L)

The AG-PRS-104 is a flush diaphragm pressure transmitter in which the process connection and measuring diaphragm form a single rod-type assembly, leaving no dead space or crevice where product can accumulate. Wetted parts are made of 316L stainless steel, laser welded and polished for cleanability.

A stable piezoresistive silicon sensor and all-stainless construction give accuracy up to ±0.5 % FS. The transmitter suits CIP/SIP-cleaned installations in food, pharmaceutical and biotech plants, as well as viscous, particle-laden or corrosive media with special diaphragm materials.

Key features

• Flush, crevice-free diaphragm suitable for CIP/SIP cleaning
• 316L stainless steel wetted parts; Hastelloy C22 or tantalum diaphragm optional
• Piezoresistive silicon sensor, accuracy up to ±0.5 % FS
• Sanitary clamp connections (SMS, DIN, ISO, 3-A types), direct or extended-tube mounting
• Output 4 to 20 mA, HART, PROFIBUS PA or FOUNDATION Fieldbus
• LCD display with push buttons; remote zero, range setting and diagnostics

Technical data

Applications

• CIP/SIP systems, fermentation and ingredient tanks, filling machines
• Bioreactors, purification systems, freeze dryers and WFI loops
• Reactors and transfer lines for creams and emulsions
• High-purity chemical transfer systems
• Slurries and corrosive media with special diaphragm materials

Hazardous areas

Explosion-proof versions are declared by the manufacturer (marking not specified in the source). Certificates (ATEX / IECEx where applicable) and hygienic certificates (e.g. 3-A, EHEDG, EC 1935/2004, FDA) are provided on request with the quotation.

Supplied on quotation and configured to your process data (range, process connection, materials, output, options). Datasheet available on request.

Supplied from a qualified manufacturer selected by ASSINOV. Origin, manufacturer details and certificates are provided with our quotation.
