Portable Pneumatic Pressure Calibrator (-95 kPa to 6 MPa)
Portable manual pneumatic pressure and vacuum source AG-CAL-107 for field calibration: -95 kPa to 6 MPa in air, 10 kPa fine adjustment, two M20 x 1.5 outputs.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The AG-CAL-107 portable pneumatic pressure calibrator is a compact, manually operated pressure and vacuum source for on-site calibration, where bench-top sources are too bulky to carry.
Used with a digital pressure calibrator of suitable range, it calibrates pressure and differential pressure transmitters, precision and standard pressure gauges and other pressure instruments.
Key features
- Simple structure and low operating effort compared with hand-clamp pumps
- Easy to carry, leak-resistant, easy to maintain
- Tolerant of dirt and humidity
- Generates vacuum and positive pressure
- Compatible with digital pressure calibrators of various ranges
- Pressure holding valve, pre-load handle, pressurising handwheel, switch and vent valves
Technical data
| Model | AG-CAL-107 |
| Pressure range | -95 kPa to 6 MPa |
| Medium | Air |
| Min. controllable adjustment | 10 kPa |
| Output ports | 2 x M20 x 1.5 |
| Dimensions | 270 x 150 x 150 mm |
| Operation | Manual, handwheel pressurisation |
Applications
- Calibration of pressure and differential pressure transmitters
- Verification of precision and industrial pressure gauges
- Testing of pressure sensors and switches
- On-site calibration in plants and at field instruments
Hazardous areas
Standard version for safe areas. Ask us for hazardous-area options.
Supplied on quotation and configured to your requirements (adapters, reference calibrator). Datasheet available on request.
Supplied from a qualified manufacturer selected by ASSINOV. Origin, manufacturer details and certificates are provided with our quotation.
AG-CAL-107
Data sheet
- Hazardous area
- Safe area (options on request)
- Output
- Pressure source (no indication)
- Process connection
- 2 x M20 x 1.5
- Measuring principle
- Manual pneumatic pressure / vacuum source
- Max. pressure
- 6 MPa
