PANAM DIN Rail Mounted Temperature Transmitters PTT-401
DIN rail temperature transmitters: PTT-401-01/02 smart dual channel for RTD and thermocouples, 4 to 20 mA + HART, accuracy ±0.1%, SIL2/SIL3 and intrinsically safe (ATEX) versions; PTT-401-03 economical Pt100/Ni100 transmitter, 4 to 20 mA, intrinsic safe version.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The PANAM PTT-401-01 converts RTD resistance or thermocouple voltage into a 4 to 20 mA + HART signal. It has two separate measuring channels for temperature difference, average, average with redundancy, maximum or minimum, with ambient and cold junction compensation. Parameters are programmed by PC with a HART/USB converter, or set by PANAM on request. The PTT-401-02 is the version with ATEX certificate.
The PTT-401-03 is an economical rail mounted transmitter for Pt100 and Ni100 sensors with 3-wire line compensation, programmed with an RS converter and configuration software; ordered parameters are printed on the serial number label.
Key features
- Galvanic insulation (in, out) on smart versions
- Programmable sensor type and measuring range
- RTD line and thermocouple cold junction compensation
- Smart versions: 4...20 mA + HART, auto diagnostics, SIL2/SIL3
- Intrinsic safe version: Ex ia IIC T4/T5 Ga, I M1 Ex ia I Ma
- Slim 12.5 mm wide module
Standard specification
| PTT-401-01/02 inputs | TC K, J, S, B, N, T, R, E; Pt10 to Pt1000, Ni100, Cu100; resistance, mV |
|---|---|
| PTT-401-01/02 output | 4...20 mA + HART |
| PTT-401-01/02 accuracy | ±0.1% |
| PTT-401-01/02 supply | 10...36 V DC (safety and Ex: 10...30 V DC) |
| PTT-401-01/02 dimensions | 12.5 x 99 x 114.5 mm (WxHxD) |
| PTT-401-03 input | Pt100, Ni100 (20 to 380 Ω), minimum range 10 Ω |
| PTT-401-03 output and accuracy | 4-20 mA, ±0.2% (ΔR > 20 Ω), supply 6...29 V DC |
| Ambient temperature | -40 to +85 °C (PTT-401-01/02), -25 to +80 °C (PTT-401-03) |
The code gives model (401), transmitter type (01 smart, 02 smart with ATEX, 03 Pt100/Ni100), SIL level, sensor type, simplex or duplex, wiring, range and alarm signal. Catalogue example: PTT-401-01-0-01-1-2-0~50-H.
Applications
Temperature signal conditioning in control rooms, marshalling cabinets and junction boxes for process and safety systems.
Documentation
The manufacturer catalogue with full dimension tables and the ISO certificates of the manufacturer are in the attachments. Indicate the model or part number, size, connections, material, pressure rating and quantity in your quotation request.
PANAM-TT-401
Data sheet
- Manufacturer series
- PTT-401
- Product type
- DIN rail temperature transmitter
- Size range
- 12.5 mm module
- Pressure rating
- NA
- Material
- Rail mounted module
- Origin
- India
