PANAM Loop Powered Signal Indicator PSI-601 (4 to 20 mA, IP66)
Loop powered digital indicator for any 4 to 20 mA device, display range -99999 to 99999 with 10 mm backlit figures, error 0.2% ±1 digit, aluminium wall or pipe mounted casing IP66 (IP67 special), intrinsic safety option II 2G Ex ia IIC T4 Gb.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The PANAM PSI-601 digital indicator can be used with any device delivering a 4 to 20 mA signal and does not require an external power supply. The reading range is configurable from -99999 to 99999 with configurable decimal point, and the display shows the units, the loop current or the percentage of range.
The aluminium casing mounts on a wall or, with the bracket, on a vertical or horizontal pipe Ø35 to Ø65 mm or a 2" pipe.
Key features
- Loop powered, no external supply
- Backlit display, 10 mm figures
- Configurable range -99999 to 99999
- Aluminium casing, IP66 (IP67 special version)
- Intrinsic safety certificate option
- Wall or pipe mounting
Standard specification
| Input signal | 4 to 20 mA |
|---|---|
| Display range | -99999 to 99999 |
| Display error | 0.2% ±1 digit |
| Voltage drop | 3 V (additional 3 V with backlight) |
| Ambient temperature | -40 to 80 °C |
| Ingress protection | IP66, special version IP67 |
| ATEX option | II 2G Ex ia IIC T4 Gb |
The code gives model (601), certification (00 none, 01 II 2G Ex ia IIC T4 Gb, 02 IP67) and accessories (01 bracket for 2" pipe). Catalogue example: PSI-601-00-00.
Applications
Local indication for transmitters and 4 to 20 mA loops in process plants and hazardous areas.
Documentation
The manufacturer catalogue with full dimension tables and the ISO certificates of the manufacturer are in the attachments. Indicate the model or part number, size, connections, material, pressure rating and quantity in your quotation request.
PANAM-SI-601
Data sheet
- Manufacturer series
- PSI-601
- Product type
- Loop powered indicator
- Size range
- 4 to 20 mA
- Pressure rating
- NA
- Material
- Aluminium casing
- Origin
- India
