PANAM Temperature Measuring Inserts PTS-505 (Pt100 and Thermocouple)
Replacement measuring inserts for temperature sensors: shield type 2 (316 / Inconel, Ø3 to Ø8 mm) for Pt100, K or J; types 4 and 5 ceramic for K, J, S and B up to 1600 °C. Single or dual elements, accuracy classes AA, A, B, 1, 2.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The PANAM PTS-505 measuring inserts are the replaceable sensing elements used inside temperature sensors and thermowells. Shield type 2 in 316 or Inconel takes Pt100 and thermocouple K or J elements; shield types 4 and 5 are ceramic for high temperature thermocouples.
The catalogue also lists clamping grips (UG, UC1, UC2, US, USG) used to mount the temperature sensors.
Key features
- Pt100 single or dual (-70 to 500 °C, low temperature -196 to 150 °C)
- TC K and J (-40 to 550 °C, K up to 1000 °C)
- TC S (0 to 1300 °C) and B (600 to 1600 °C) in ceramic shields
- Stem diameters 3, 4.5, 6, 8 mm (type 2)
- Accuracy classes AA, A, B, 1, 2
- Junction types O, P, Z
Standard specification
| Shield type 2 | 316 / Inconel; Pt100, K, J; Ø3, Ø4.5, Ø6, Ø8 mm |
|---|---|
| Shield type 4 | Ceramic; K, J, B |
| Shield type 5 | Ceramic; K |
| Ranges | Pt -70 to 500 °C; K -40 to 1000 °C; S 0 to 1300 °C; B 600 to 1600 °C |
| RTD wiring | 2, 3 or 4 wires |
| Accessories | Clamping grips UG (316 SS), UC1, UC2, US, USG |
The code gives model (505), shield type, diameter, stem length, sensor type, accuracy class, number of RTD wires and junction type. Catalogue example: PTS-505-2-0-15-02-1-0-N.
Applications
Spare and replacement inserts for industrial temperature sensors in process, power and high temperature applications.
Documentation
The manufacturer catalogue with full dimension tables and the ISO certificates of the manufacturer are in the attachments. Indicate the model or part number, size, connections, material, pressure rating and quantity in your quotation request.
PANAM-TS-505
Data sheet
- Manufacturer series
- PTS-505
- Product type
- Temperature measuring insert
- Size range
- 3 to 8 mm
- Pressure rating
- NA
- Material
- 316 Inconel or ceramic
- Origin
- India
