PANAM Bellow Differential Pressure Gauge PD100
PD100 bellows type differential pressure gauges from the PANAM gauge range (SS 316 / SS 316L, dial sizes 63 to 150 mm, IP54 to IP67, 130% overload protection). Options: NACE, valves, electric contacts.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The PANAM PD100 is a bellows type differential pressure gauge, used to indicate the pressure difference between two process points, for example across filters, strainers or flow elements. It belongs to the PANAM pressure gauge range.
The detailed model data sheet (ranges, dimensions and ordering code) is given in the PANAM pressure gauge catalogue attached below. PANAM pressure gauges can be combined with PANAM gauge valves, gauge savers, syphons and diaphragm seals to form a complete instrument hook-up; please send your range, connection and service conditions for a quotation.
Key features
- Bellows measuring element for differential pressure
- Dial sizes 63 mm, 100 mm, 115 mm and 150 mm (others on request)
- Ingress protection according to IP54, IP65, IP66 or IP67
- Overload protection 130%
- Stem mounting as standard, panel, bracket or surface mounting on request
- NACE option for sour service
- Can be supplied with diaphragm seals, valves, electric contacts, dampener, gauge saver or syphon
Standard specification
| Model | PD100 |
|---|---|
| Product type | Bellow Differential Pressure Gauge |
| Wetted / case material (range) | SS 316 and SS 316L |
| Dial sizes (range) | 63 mm, 100 mm, 115 mm, 150 mm etc. |
| Protection | IP54 / IP65 / IP66 / IP67 |
| Filling | Dry, or filled with glycerin, silicon, halocarbon or other upon request |
| Mounting | Standard stem; panel, bracket, surface or others on request |
| Overload protection | 130% |
| Options | NACE, diaphragm seals, valves, electric contacts, dampener, gauge saver, syphon |
Applications
Pressure measurement in oil and gas, refineries, petrochemical and chemical plants, power generation, offshore installations and general process industries.
Documentation
The manufacturer catalogue with the complete technical data and the ISO certificates of the manufacturer are in the attachments. Indicate the model or part number, size, connections, material, pressure rating and quantity in your quotation request.
PANAM-PG-PD100
Data sheet
- Manufacturer series
- PD100
- Product type
- Differential pressure gauge
- Size range
- 63 to 150 mm dial
- Pressure rating
- 130% overload protection
- Material
- SS 316 and SS 316L
- Origin
- India
