PANAM Tube Fitting Ferrules, Nuts, Ferrule Sets and Pipe Inserts
Spare front ferrules (PFF), back ferrules (PBF), nuts (PN), ferrule sets (PFS, PNFS and 10 or 5 piece packs) and pipe inserts (PIN) for PANAM twin ferrule tube fittings, imperial 1/16" to 2" and metric 2 to 50 mm. SS 316 standard.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
All PANAM front and back ferrules can be purchased separately, as a set, or complete with a nut. Packing ferrules in sets simplifies storage and installation and protects them against damage during transportation.
Pipe inserts (PIN) are fitted inside soft or thin wall tubing to support the tube under the ferrules. They are offered for imperial tube OD 3/16" to 1" and metric tube OD 6 to 12 mm, matched to the tube inside diameter.
Key features
- Front ferrule (PFF), back ferrule (PBF) and nut (PN) available individually
- PFS set: one front and one back ferrule
- PNFS set: front and back ferrule with nut
- PFS-SET pack: 10 front and 10 back ferrules
- PNFS-SET pack: 5 front ferrules, 5 back ferrules and 5 nuts
- Pipe inserts PIN for imperial and metric tubing
- Same sizes and materials as PANAM tube fittings
Standard specification
| Imperial sizes | 1/16" to 2" tube OD |
|---|---|
| Metric sizes | 2 mm to 50 mm tube OD (ferrules listed 2 to 28 mm in tables) |
| Standard material | SS 316 |
| Other materials | As per tube fitting material designators (alloys on request) |
| Nut threads | Silver plated to prevent galling |
| Pipe insert range | Imperial 3/16" to 1" OD; metric 6 to 12 mm OD |
Ordering examples
| Item | Content | Example |
|---|---|---|
| Front ferrule | 1 front ferrule | PFF-04-SS |
| Back ferrule | 1 back ferrule | PBF-M06-SS |
| Nut | 1 nut | PN-06-SS |
| Ferrule set | 1 front + 1 back ferrule | PFS-04 (1/4"), PFS-M06 (6 mm) |
| Ferrule and nut set | Front + back ferrule + nut | PNFS-06 (3/8"), PNFS-M08 (8 mm) |
| 10 ferrule sets | 10 front + 10 back ferrules | PFS-08-SET, PFS-M12-SET |
| 5 sets with nuts | 5 front + 5 back ferrules + 5 nuts | PNFS-12-SET, PNFS-M14-SET |
| Pipe insert | Insert for tube OD x tube ID | PIN-06-04-SS, PIN-M10-M08-SS |
Specify the item code followed by the tube OD code: imperial in sixteenths of an inch (04 = 1/4") or metric with M (M06 = 6 mm). Example from the catalogue: PFS-08-SET is a pack of 10 ferrule sets for 1/2" tube.
Applications
Maintenance stock and spare parts for instrumentation tubing systems in Oil and gas production, refineries, petrochemical and chemical plants, power generation, offshore installations and analyzer or instrument hook-ups.
Documentation
The manufacturer catalogue with full dimension tables and the ISO certificates of the manufacturer are in the attachments. Indicate the model or part number, size, connections, material, pressure rating and quantity in your quotation request.
PANAM-TF-FK
Data sheet
- Manufacturer series
- Ferrules and nuts
- Product type
- Tube fitting spare parts
- Size range
- 1/16 in to 2 in and 2 to 50 mm
- Pressure rating
- As tube fitting
- Material
- SS 316 standard
- Origin
- India
