PANAM Dielectric Tube Fittings (Union and Male Connector, 5,000 psi)
Dielectric union and male connector tube fittings isolating instruments from electric currents, voltage and static discharge. SS 316 body with polyamideimide insulator, 5000 psi (34.47 MPa), -40 to 93 °C. Tube OD 1/4" to 1/2" and 6 to 12 mm, 1/4" NPT male end.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
PANAM dielectric fittings are designed to isolate instruments and measuring equipment from the effects of electric currents, voltage and static discharges. They are built from SS 316 for aggressive environments with a polyamideimide insulator offering high electrical, chemical and UV resistance and low water absorption, maintaining dielectric strength over a wide climatic range.
Two configurations are offered: union dielectric fittings (tube to tube) and male connector dielectric fittings (tube to NPT). Both use PANAM twin ferrule tube ends and provide maximum flow throughout.
Key features
- Electrical isolation of instruments from currents, voltage and static discharge
- Polyamideimide insulator with high electrical, chemical and UV resistance
- SS 316 (ASTM A479) body, nuts and ferrules
- PTFE packing and Viton O-ring
- Twin ferrule tube ends; NPT male end on male connector version
- Maximum flow throughout
Standard specification
| Pressure rating | 34.47 MPa (5000 psi) |
|---|---|
| Temperature rating | -40 °C to 93 °C (-40 °F to 200 °F) |
| Insulator resistance | 10 x 10^6 Ohm at 30 V DC at 20 °C (70 °F) |
| Body material | ASTM A479 316 SS |
| Insulator | Polyamideimide |
| Seals | PTFE packing, Viton O-ring |
| Union sizes | 1/4", 3/8", 1/2" and 6, 8, 10, 12 mm tube OD |
| Male connector sizes | 3/8" and 1/2" tube x 1/4" NPT; 12 mm tube x 1/4" NPT |
Range
| Type | Tube OD | Example part number |
|---|---|---|
| Union dielectric fitting | 1/4", 3/8", 1/2" | PU-04-SS-DIE |
| Union dielectric fitting | 6, 8, 10, 12 mm | PU-M06-SS-DIE |
| Male connector dielectric fitting | 3/8", 1/2" x 1/4" NPT | PMC-06-4N-SS-DIE |
| Male connector dielectric fitting | 12 mm x 1/4" NPT | PMC-M12-4N-SS-DIE |
Dielectric versions use the standard tube fitting part number with the suffix DIE. Example: PU-06-SS-DIE is a 3/8" union dielectric fitting in SS 316.
Applications
Isolation of pressure instruments, transmitters and analyzers on cathodically protected or electrically noisy lines in oil and gas, refining, petrochemical and power plants.
Documentation
The manufacturer catalogue with full dimension tables and the ISO certificates of the manufacturer are in the attachments. Indicate the model or part number, size, connections, material, pressure rating and quantity in your quotation request.
PANAM-TF-DIE
Data sheet
- Manufacturer series
- DIE
- Product type
- Dielectric tube fitting
- Size range
- 1/4 in to 1/2 in and 6 to 12 mm
- Pressure rating
- 5000 psi
- Material
- SS 316 with polyamideimide insulator
- Origin
- India
