KOSO 301R PVDF Acid Resistant Ball Valve
Acid resistant ball valve with PVDF or PTFE wetted parts and protective metal cover, 1" to 4", ASME Class 150, for corrosive fluids.
Certified equipment
ATEX / IECEx documentation supplied where stated
Worldwide delivery
Incoterms agreed in each quotation
Quotation first
Price, lead time and certificates in every offer
The KOSO 301R series acid resistant ball valves have PTFE or polyvinylidene fluoride (PVDF) wetted parts with excellent resistance to acids and corrosive fluids. The outside of the wetted part is protected by a cast iron or stainless steel cover.
Key features
- PVDF ball and body lining
- Pure PTFE seats, tight shut-off
- Ductile iron or stainless steel cover
- Wafer or wafer tapped connections
Standard specification
| Body type | 301R |
|---|---|
| Full bore size | 1"(25A) to 2 1/2"(65A) |
| Reduced bore size | 3" × 2 1/2 " to 4" × 3" |
| Body rating | ANSI Class 150, JIS 10K |
| Fluid temperature | 0 to +100°C |
| Connections | Wafer or Wafer Tapped |
| Body materials | Polyvinyliden fluoride Covered/FCD or SCS13A |
| Ball materials | Polyvinyliden fluoride |
| Seal ring materials | Pure Teflon |
| Seat Leakage | Tight shut off |
| Actuator combination | 6300RB, 6500RA, 7300RA: Pneumatic Cylinder Actuator 3200RA, 3300RA, 3400RB: Electric Motor Actuator |
Applications
Modulating and on-off service on liquids, gases and slurries in oil and gas, chemical, petrochemical, pulp and paper, water and power plants.
Documentation
Detailed datasheets are available on request. Send us your process data (fluid, flow, pressures, temperature, line size and rating) with your quotation request so that KOSO can size and select the right model.
KOSO-301R
Data sheet
- Manufacturer series
- 301R
- Product type
- PVDF acid resistant ball valve
- Size range
- 1 in to 4 in
- Origin
- KOSO group
- Rating / output
- ASME 150
